Evaporator
    • Energy conservation Standard Ceiling Type Two Fans Air Cooler Cold Room Evaporator

    • Expert Fan System Integration

      • DJ12DJ15XiamanjialiangDJ20-23°CDJ30DJ40DJ55
    • Get A Quote
    • Description
    • Features

    Standard Ceiling Type Two Fans Air Cooler Cold Room Evaporator


    ModelDJ12DJ15DJ20DJ30DJ40DJ55
    Refrige-Rating Capacity1.9KW2.3KW3.1KW4.7KW6.2KW8.5KW
    Cooling Area12㎡15㎡20㎡30㎡40㎡5㎡
    Diameter of Feed Inlet12mm12mm16mm16mm19mm19mm
    Diameter of Tail Pipe16mm16mm25mm25mm32mm32mm
    Wind Rate2450*2m³/h2450*2m³/h3950*2m³/h3950*2m³/h5400*2m³/h5400*2m³/h
    Quantity2N2N2N2N2N2N
    Fan Blade350mm350mm400mm400mm450mm450mm
    Voltage380v380v380v380v380v380v
    Power2*150W2*150W2*180W2*180W2*280W2*280W
    Air Throw8m8m10m10m15m15m
    Coil Unit1.8KW2.4KW2.6KW3.0KW3.6KW6KW
    Drain Pan0.9KW1.2KW1.3KW1.5KW1.2KW1.2KW



    On site factory

    We have more than 20 years of experience in the refrigeration field. We are young, energetic, innovative and confident! Our products are now sold to some countries in South America, Asia, the Middle East, Europe, Oceania and Africa. Our stable quality, competitive prices and timely services have helped us win more and more customers.


    In the future, we believe you can enjoy more fresh life in our industry. We hope to realize this dream together with you and help more and more people enjoy a high quality of life.


    FAQ

    Q1: I would like to know which places are the main export markets of DJ evaporators?
    A1: So far, we have exported to more than 112 countries, our products are very popular, not only limited to regions with hot weather, regions with low temperature such as Russia will also use our cold storage to preserve vegetables and fruits in cold winter.
    Q2: If I want to buy DJ evaporator I want to see your samples is that okay?
    A2: Each of our products can provide samples, you need to pay the sample fee
