10hp evaporator for cold room
  • 10hp evaporator for cold roomevaporation unit support for cold roomevaporator unit cooler for cold room
    • Chinese Suppliers Low Temp DL Type Energy Saving High Quality Cold Room Evaporator

    • Turbocharged Ventilation Power

      • DL20DL25DL40DL55DL80DL105XiamanJialiang+5℃
    • Get A Quote
    • Description
    • Features

    Chinese Suppliers Low Temp DL Type Energy Saving High Quality Cold Room Evaporator


    Product Description




    ModelDL20DL25DL40DL55DL80DL105
    Refrige-Rating Capacity4.3KW5.3KW8.4KW11.6KW16.8KW23.2KW
    Cooling Area22㎡25㎡40㎡55㎡80㎡105㎡
    Diameter of Feed Inlet12mm12mm16mm16mm19mm19mm
    Diameter of Tail Pipe16mm16mm25mm25mm32mm32mm
    Wind Rate2450*2m³/h2450*2m³/h3950*2m³/h3950*2m³/h5400*2m³/h5400*2m³/h
    Quantity2N2N2N2N2N2N
    Fan Blade350mm350mm400mm400mm450mm450mm
    Voltage380v380v380v380v380v380v
    Power2*150W2*150W2*180W2*180W2*180W2*180W
    Air Throw8m8m10m10m15m15m
    Coil Unit0.9KW1.2KW1.3KW1.5KW2.4KW3.6KW
    Drain Pan0.9KW1.2KW1.3KW1.5KW1.2KW1.2KW



    On Site Factory


    Feature:

    1. The shell is made of special galvanized steel, which has high strength, corrosion resistance, shock resistance and gloss. It can also be made of aluminum, stainless steel and other materials according to customer needs.

    2.  The drain pan is designed so that the sewage faces the drain, which effectively reduces the accumulation of water in the pan.

    3.  The use of high-quality copper tubes and special aluminum fins.,which increases the surface area and heat transfer efficiency.

    4. The pipeline design adopts a direct return oil counterflow heat exchanger to avoid accumulation of refrigerated oil, make full use of the heat transfer area, improve heat exchange efficiency, and ensure overheating.




    FAQ


    Q1: Can we do our OEM logo DL series evaporator?
    A1: Yes, accept customization
    Q2: Could your factory accept customized DL series evaporator?
    A2: We can do customized dimension according to customers'requirements. We have access to all the leading Cold Room refrigerators brands and can offer independent advice, and recommend right equipment to meet your business requirements.
    Q3: How long delivery time DL series evaporator?
    A3: Customized products, generally 30 working days, the specific situation is confirmed according to the product demand
