Factory 380V 2-fan Air Cooler Evaporator
| Processing Room Project | |
| Project size | 7(L)*20(W)*2.8(H)M |
| Indoor temperature | +15℃ |
| Number of people in the Processing Room | 40 Workers Working In Processing Room |
| Condensing Units Horsepower | 12HP |
| Evaporator Model | SDL-80 |
| Model | DL80 | DL105 | DL125 |
| Cooling Capacity | 8.0 kW | 10.5kW | 12.5 kW |
| Fan Diameter | 400 mm x4 | 450 mm x4 | 500 mm x 4 |
| Air Volume | 6,800 m³/h | 9,200 m³/h | 12,000 m3/h |
| Motor Power | .25kWx4 | 0.37kW x4 | 0.55 kW x 4 |
| Defrost Type | Electric Defrost | Electric Defrost | Electric Defrost |
| Fin Spacing | 4.5 mm | 4.5 mm | 6.0 mm |
| Coil Material | Copper Tube + Aluminum Fin | Copper Tube + Aluminum Fin | Copper Tube + Aluminum Fin |
| Voltage | 220V/380V/420V/460V | 220V/380V/420V/460V | 220V/380V/420V/460V |
| Dimensions (Lx Wx H) | 2,200 x 1,100 x 550 mm | 2,400 x 1,100 x 550 mm | 2,400 x 1,100 x 550 mm |
FAQ
Q1:What types of evaporators are available?
A2: High-temperature, medium-temperature, and low-temperature models are available, with different fin spacing and defrost options.
Q2: Can the evaporator fan voltage be customized?
A2: Yes. Fan motors can be selected according to the electrical standards of different countries.
Q3: What is the air throw distance?
A3: Air throw depends on fan diameter, speed, installation position, and evaporator model.
Q4: How do I select the correct evaporator?
A4: Selection depends on cold room size, target temperature, cooling capacity, refrigerant, evaporating temperature, and defrost method.
