    Easy To Install Customized Pu Sandwich Panels for Cold Room


    Feature:

    The polyurethane cold room panel uses lightweight polyurethane as the inner material of the cold room panel. The advantage of polyurethane is that its insulation performance is very good. The outer part of the polyurethane cold room panel is made of colored steel plates and stainless steel plate components. The advantage of this is to prevent the cold room panel from spreading temperature due to the large temperature difference between inside and outside, thereby making the cold room more energy-efficient and improving the work efficiency of the cold room. The cold room panel has the characteristics of corrosion resistance, aging resistance, flame retardancy, strong pressure resistance, beautiful appearance, convenient operation, long service life, sanitation, etc

    Density (Kg/m3)38-45
    Bending Strength (Mpa)>0.25
    Compressive Strength (Mpa)>0.2
    Thermal Conductivity(W/n℃)<0.022
    Water absorption (KG/m3)<0.30
    Self-extinguish time (S)<7S
    DimensionLength(m)*Width(m)*Height(m)
    PanelNew material polyurethane insulation panel,40~45kg/m3
    Width of Panel960mm, ect. (customized)
    Height of Panel1 to 12m
    Panel thickness50mm,75mm,100mm, 120mm,150mm,200mm
    Color steel thickness0.326/0.376/0.426/0.476/0.5mm
    Type of doorSliding door,swing door,double door
    Temp. of room-60℃~+20℃ optional
    Company CertificationsISO 9001: 2000 SGS SASO CE
    Business TypeManufacturer

    Customized Services


    Panel thicknessSuitable temperature for cold roomStroge Product
    50mm5℃~15℃Fruit,Vegetable,Flower
    100mm-15℃~5℃Tea,Cheese,French fries
    120mm-15℃~-20℃
    		Meat,Seafood
    150mm-20℃~-30℃Ice cream,Shrimp
    200mm
    		below -30℃Frozen food,Tuna

    FAQ

    Q1: What is a cold room panel?

    A1: Cold room panel is a kind of insulation material used to construct cold storage and freezing environment, and it is often used in the construction of cold storage, cold room and freezer.

    Q2: What are the main materials of cold room panels?

    A2: Cold room panels mainly use materials such as polyurethane and polystyrene (EPS), which have good thermal insulation properties.
