PU Cam Lock Cold Room Panels for Cold Storage: Superior Temperature Control
Versatile Temperature Control: Ideal for managing temperature in both low and high-temperature environments.
Exceptional Thermal Efficiency: These panels excel at preserving the desired internal temperature, ensuring a well-regulated environment.
Minimal Air Infiltration: Their design guarantees low air leakage, enhancing energy efficiency.
Substantial Energy Savings: These panels make a significant impact by reducing energy consumption and operational expenses.
| Density (Kg/m3) | 38-45 |
| Bending Strength (Mpa) | >0.25 |
| Compressive Strength (Mpa) | >0.2 |
| Thermal Conductivity(W/n℃) | <0.022 |
| Water absorption (KG/m3) | <0.30 |
| Self-extinguish time (S) | <7S |
| Dimension | Length(m)*Width(m)*Height(m) |
| Color steel thickness | 0.326/0.376/0.426/0.476/0.5mm |
| Aluminum flower thickness | 1.5/2.0/3.0mm |
| Stainless steel thickness | 0.4/0.5mm |
| Panel | New material polyurethane insulation panel,40~45kg/m3 |
| Width of Panel | 960mm, ect. (customized) |
| Height of Panel | 1 to 12m |
| Panel thickness | 50mm,75mm,100mm, 120mm,150mm,200mm |
| Type of door | Sliding door,swing door,double door |
| Temp. of room | -60℃~+20℃ optional |
| Company Certifications | ISO 9001: 2000 SGS SASO CE |
| Business Type | Manufacturer |
Customized Services
FAQ
Q1: What are the maintenance methods for cold room panels? |
A1: Regularly check panel joints and seals to ensure there are no breaks or leaks. |
Q2: Are cold room panels reusable? |
A2: Yes, cold room panels can usually be disassembled and assembled multiple times, suitable for multiple uses. |
