- High Efficiency and energy saving integrated refrigeration unit
Modular design, flexible and adaptable
- Get A Quote
- Description
- Features
High Efficiency and energy saving integrated refrigeration unit
| Side Embedded Fixed Frequency Monoblock Unit | ||||||
| Model | Voltage | Power | Packaging Size (mm) | Product Weight(kg) | Freezer Room Volume | Cold Room Volume |
| XMJL-YTCN10 | 220V | 220V/50Hz | 670*880*800 | 113 | ≤7m³ | ≤12m³ |
| 220V/60Hz | ||||||
| XMJL-YTCN20 | 220V | 220V/50Hz | 820*1000*1000 | 130 | ≤15m³ | ≤25m³ |
| 220V/60Hz | ||||||
| 380V | 380/50Hz | |||||
| XMJL-YTCN30 | 220V | 220V/50Hz | 1050*1000*1000 | 165 | ≤25m³ | ≤40m³ |
| 220V/60Hz | ||||||
| 380V | 380/50Hz | |||||
| XMJL-YTCN40 | 380V | 380V/50Hz | 1120*1070*1060 | 190 | ≤35m³ | ≤55m³ |
| Side Embedded Frequency Conversion Monoblock Unit | |||||
| Model | Supply Voltage | Packaging Size (mm) | Product Weight(kg) | Freezer Room Volume | Cold Room Volume |
| XMJL-BYTCN10 | 220V/50HZ/60Hz | 670*880*800 | 113 | ≤7m³ | ≤12m³ |
| XMJL-BYTCN20 | 220V/50HZ/60Hz | 820*1000*1000 | 130 | ≤15m³ | ≤25m³ |
| XMJL-BYTCN30 | 220V/50HZ/60Hz | 1050*1000*1000 | 165 | ≤25m³ | ≤40m³ |
| XMJL-BYTCN40 | 220V/50HZ/60Hz | 1120*1070*1060 | 185 | ≤35m³ | ≤55m³ |
| Top Mounted Fixed Frequency Monoblock Unit | |||||
| Model | Supply Voltage | Packaging Size (mm) | Product Weight(kg) | Freezer Room Volume | Cold Room Volume |
| XMJL--YTDN10 | 220V/50Hz | 1000*570*810 | 95 | ≤7m³ | ≤12m³ |
| 220V/60Hz | |||||
| XMJL--YTDN20 | 220V/50Hz | 1240*635*810 | 125 | ≤15m³ | ≤25m³ |
| 220V/50Hz | |||||
| 380/50Hz | |||||
| XMJL--YTDN30 | 220V/50Hz | 1410*670*865 | 150 | ≤25m³ | ≤40m³ |
| 220V/60Hz | |||||
| 380V/50Hz | |||||
Customized Services
FAQ
| Q1: How is the maintenance of the monoblock condensing unit performed? |
| A1: The maintenance of the monoblock condensing unit includes regular cleaning, refrigerant inspection, and equipment servicing. |
| Q2: How long is the installation period of the monoblock condensing unit? |
| A2: The installation period of the monoblock condensing unit is usually relatively short, ranging from a few days to several weeks depending on the size and requirements. |
