    Factory Direct Supply Low Noise Cold Room Evaporator

    DD Series for Medium Temperature Standard Evaporator

    ModelCooling CapacityCooling AreaInlet PipeTail PipeWind Rate QuantityFan BladeVoltagePower
    DD152.6KW15㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DD223.9KW22㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DD305.3KW30㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DD407.0KW40㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DD6010.5KW60㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DD8014.0KW80㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DD10017.5KW100㎡19mm38mm5400*2m³/h3N450mm380V2*280W
    DD12021KW120㎡19mm38mm5400*3m³/h3N450mm380V2*280W
    DD14024.5KW140㎡25mm42mm5400*4m³/h4N450mm380V2*280W
    DD16028.0KW160㎡25mm42mm5400*4m³/h4N450mm380V2*280W
    DD20035.0KW200㎡25mm50mm12000*2m³/h2N600mm380V3*1500W
    DD25043.8KW250㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DD31054.3KW310㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DD36063.0KW360㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DD44077.0KW440㎡28mm50mm12000*4m³/h4N600mm380V4*1500W

    DL Series for High Temperature Standard Evaporator

    ModelCooling capacityCooling areaInlet pipeTail PipeWind RateQuantityFan BladeVoltagePower
    DL204.3KW22㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DL25580㎡25㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DL408.4KW40㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DL5511.6KW55㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DL8016.8KW80㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DL10523.2KW105㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DL12527.6KW125㎡19mm38mm5400*3m³/h2N450mm380V2*280W
    DL16034.6KW160㎡19mm38mm5400*3m³/h3N450mm380V2*280W
    DL18540.3KW185㎡25mm42mm5400*4m³/h4N450mm380V2*280W
    DL21046.1KW200㎡25mm42mm5400*4m³/h4N450mm380V2*280W
    DL26052.0KW260㎡25mm50mm12000*2m³/h2N600mm380V3*1500W
    DL33066.0KW330㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DL41082.0KW410㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DL47094.0KW470㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DL580116.0KW580㎡28mm50mm12000*4m³/h4N600mm380V4*1500W

    DJ Series for Low Temperature Standard Evaporator

    ModelCooling CapacityCooling AreaInlet PipeTail PipeWind RateQuantityFan BladeVoltagePower
    DJ121.9KW12㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DJ152.3KW15㎡12mm16mm2450*2m³/h2N350mm380V2*150W
    DJ203.1KW20㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DJ304.7KW30㎡16mm25mm3950*2m³/h2N400mm380V2*180W
    DJ406.2KW40㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DJ558.5KW55㎡19mm32mm5400*2m³/h2N450mm380V2*280W
    DJ7027.6KW125㎡19mm38mm5400*3m³/h3N450mm380V2*280W
    DJ8534.6KW160㎡19mm38mm5400*3m³/h3N450mm380V2*280W
    DJ10040.3KW185㎡25mm42mm5400*4m³/h4N450mm380V2*280W
    DJ11546.1KW200㎡25mm42mm12000*2m³/h4N450mm380V2*280W
    DJ14021.7KW140㎡25mm50mm12000*2m³/h2N600mm380V3*1500W
    DJ17026.4KW170㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DJ21032.6KW210㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DJ25038.8KW250㎡25mm50mm12000*3m³/h3N600mm380V3*1500W
    DJ30046.5KW300㎡28mm50mm12000*4m³/h4N600mm380V4*1500W




    Customized Services

    FAQ

    Q1: Does availing the option for product customization with our branding involve any additional charges?

    A1: The OEM service is offered without any additional costs.

    Q2: What assurances or measures are in place to ensure the quality of the products?

    A2: We always provide a pre-production sample before commencing mass production.
