- Long Life 3HP Condensing Unit Project
Special transportation refrigeration equipment for emergency medical drugs to ensure the safety of the entire cold chain
- Get A Quote
3HP380V(50hz)440v(60Hz)220V(50hz)
- Description
- Features
Long Life 3HP Condensing Unit Project
| Three Phase Condensing Unit | ||||||
| Model | MLZ015 | MLZ019 | MLZ021 | MLZ026 | MLZ030 | MLZ038 |
| Horse Power | 2HP | 2.5HP | 3HP | 3.5HP | 4HP | 5HP |
| Compressor | Danfoss | |||||
| Refrigeration Capacity | 4100W | 5500W | 5800W | 7200W | 8500W | 10200W |
| Btu/h | 14000 | 18800 | 19800 | 24600 | 29000 | 34800 |
| Input Power | 2.1W | 2.58W | 2.74W | 3.44W | 3.9W | 4.7W |
| COP（W/W） | 1.94 | 2.11 | 2.13 | 2.1 | 2.18 | 2.18 |
| EER（Btu/h/W） | 6.62 | 7.2 | 7.27 | 7.17 | 7.44 | 7.44 |
| cm3/rev | 33.8 | 43.5 | 46.2 | 57.1 | 68.8 | 81 |
| m3/h | 7.1 | 9.1 | 9.7 | 12 | 14.4 | 17 |
| Oil Injection Volume | 1.1L | 1.1L | 1.1L | 1.1L | 1.6L | 1.6L |
| Net Weight (With Oil) | 31kg | 31kg | 31kg | 31kg | 37kg | 37kg |
| Condensing Temperature | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ |
| Voltage Range | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) |
Customized Services
FAQ
| Q1: What is the insulation performance of a danfoss condensing unit? |
A1: Danfoss condensing units typically use high-quality insulation materials to ensure temperature stability inside the cold storage and reduce energy loss. |
Q2: Does a danfoss condensing unit have an emergency shutdown button? |
A2: Yes, danfoss condensing units are usually equipped with emergency shutdown buttons for quickly turning off the unit in case of emergencies. |
