condensing unit
    • Factory Walk in Customized 6G-30.2 30HP Blast Freezer Air Cooled Condense Unit

    • Tailored Customization of Cold Storage Units

      • 6G-30.2R404aXiamen JialiangAir Cooled-11℃~-28℃
    • Get A Quote
    • Description
    • Features

    6G-30.2 30HP Blast Freezer Air Cooled Condense Unit

    Our Promises:

    1. Flexible Configuration: We are dedicated to providing customizable configurations that meet your specific needs. The unit's accessories, including the condenser and liquid receiver, can be tailored to your requirements. You also have the option to upgrade components like the oil filter, solenoid valve, sight glass, or pressure controller with internationally recognized accessories.

    2. Exquisite Design: Our commitment to excellence extends to the design of our units. Not only do they feature a beautiful and elegant appearance, but every aspect, including the pipelines, has been meticulously crafted by professional designers. Years of customer feedback have ensured that our pipeline design aligns perfectly with operational requirements.

    3. Uncompromising Quality: We prioritize delivering top-notch quality in every aspect of our units. From high-quality accessories to a professionally designed structure and dependable operation, our units are built to last. The exterior is treated with an advanced spraying process, resulting in a uniform and vibrant finish that does not peel off. Your satisfaction is our priority, and we stand behind the quality of our products.

    Brand NameXiamen Jialiang
    Compressor6G-30.2
    Compressor BrandXiamen Jialiang
    Condensing Temperature40℃
    Warranty1 Year
    Temperature Range-10℃~15℃
    Refrigeration Unit BrandXiamen Jialiang
    Cooling Capacity（The temperature is -5℃）87.6 KW
    Evaporator Capacity（The temperature is -5℃）87.6 KW
    Voltage Range

    380~420YY/3/50


    440~480YY/3/60

    Engine Displacement (50Hz) m/h126.8 m
    Current (400V)53 A
    Horse Power30 HP
    SizeCustomzised
    Compressor TypeSemi-hermitic Reciprocating Compressors
    RefrigerantR22/R404a/R447a/R448a/R449a/R507a
    Refrigeration TypeAir Cooled/Water Cooled/Evaporation Cooled

    Customized Services

    Key Features:

    Compact and Elegant Design: Our units boast a sleek and sophisticated appearance, adding a touch of sophistication to any setting.

    Ready for Immediate Installation: We offer fully assembled units that are prepared for immediate installation. This not only saves valuable time but also reduces assembly and application costs.

    Versatile Operating Range: Our units are designed to perform reliably across a wide range of conditions, ensuring adaptability to diverse environments.

    FAQ

    Q1: What are the power requirements of 6G-40.2 condensing unit?

    A1: The power requirements of a condensing unit depend on its cooling capacity and control system. You can refer to the product manual or contact the supplier for detailed power requirements

    Q2: What are the application areas of the 6G-40.2 condensing unit?

    A2: Condensing units are widely used in cold storage, refrigeration equipment, commercial refrigerators, and other fields, providing refrigeration solutions for food storage and preservation.
