    4EES-4Y 4HP Lower Noise Outdoor Condensing Unit

    Special Design for Construction:

    Our construction design is compact, featuring a protective cover for enhanced stability, extended service life, and an appealing appearance.

    We've implemented an excellent design for the moving components, significantly reducing vibrations.

    Furthermore, we've incorporated a well-thought-out suction device to ensure the compressor cylinder remains adequately cooled.

    Brand NameXiamen Jialiang
    Compressor4EES-4Y
    Compressor BrandBitzer
    Capacity Steps100%
    Warranty1 Year
    Temperature Range- 11 °C ~ -28 °C
    Refrigeration Unit BrandXiamen Jialiang
    Cooling Capacity(The temperature is 0℃)6.81 KW
    Evaporator Capacity(The temperature is 0℃)6.81 KW
    Power Input(The temperature is 0℃)4.16 KW
    Current (400V)7.24 A
    Horse Power4 HP
    Voltage Range380-420V
    SizeCustomzised
    Compressor TypeSemi-hermitic Reciprocating Compressors
    RefrigerantR22/R404a/R447a/R448a/R449a/R507a
    Refrigeration TypeAir Cooled/Water Cooled/Evaporation Cooled

    Customized Services


    The motor is equipped with an electronic module protector or advanced heat protector to maintain optimal temperature control.

    Additionally, we've installed a crankcase heater to prevent any unwanted liquid migration.

    FAQ

    Q1: Could you please provide the installation procedure for the 4EES-4Y condenser unit refrigeration equipment?

    A1: We will send layout diagrams and English installation videos, and have a dedicated after-sales group that can provide remote guidance for you

    Q2: Which market is the primary consumer of the 4EES-4Y condenser unit products?

    A2: Our products are all over the country
