Condensing Unit
    • Safe And Reliable Refrigeration ZSI Series China Factory Price Three Phase Condensing Unit

    • High-Quality 380V Condenser Unit from Xiamen Jialiang's ZSI Series at Competitive Factory Prices

      • 5hp compressor condensing unitcondensing unit design2 stage condensing unit15 hp condensing unitcondensing unit air cooled
    • Get A Quote
    • Description
    • Features

    ZSI Series China Factory Price Three Phase Condensing Unit


    - High-efficiency forced air-cooled condenser, high heat exchange capacity and low electricity bill


    - Suitable for medium and low temperatures.


    - Suitable for refrigerant R404a


    - Standard configuration of standard forced air-cooled condensing unit:


    1. Compressor 2. Condenser 3. Oil heating 4. Liquid reservoir 5. Filter 6. Sight glass 7. Solenoid valve 8. H/L P meter 9. Mechanical pressure controller 10. Oil pressure protection 11. Vibration suppression 12. Oil separator 13. Gas separator 14. Oil suction filter


    ZSI Series Condensing Unit Three Phase Electricity
    ModelCondensing TemperatureRefrigeration Capacity (-15 ℃)Power (-15 ℃)VoltageTemperatureHorse Power
    ZSI06KQE40℃3.13KW
    		1.72KW380V-23℃~-10℃2HP
    ZSI08KQE40℃3.87KW1.83KW380V-23℃~-10℃3HP
    ZSI11KQE40℃5.38KW2.38KW380V-23℃~-10℃4HP
    ZSI15KQE40℃7.66KW3.4KW380V-23℃~-10℃5HP
    ZSI18KQE40℃9.48KW4.29KW380V-23℃~-10℃6HP
    ZSI21KQE40℃10.57KW4.7KW380V-23℃~-10℃7HP






    FAQ

    Q1: Does the Three Phase condensing unit have a drainage device?
    A1: Yes, condensing units typically have a drainage device to discharge the condensate generated during the refrigeration process.
    Q2: What is the refrigeration pipe layout of the Three Phase condensing unit?
    A2: The refrigeration pipe layout of the condensing unit varies based on the model and design. Generally, the refrigeration pipe layout should be well-designed to ensure smooth refrigerant flow and improve cooling efficiency.
