monoblock cooling unit
    • Wall Mounted Monoblock Cold Room For Restaurant Monoblock Freezer Units For Sale

    • monoblock condensing unit is a self-contained refrigeration system where all the components, including the compressor, condenser, and evaporator, are housed within a single unit.

    • Get A Quote
    • Description
    • Features

    Wall Mounted Monoblock Cold Room For Restaurant Monoblock Freezer Units For Sale


    Product Introduction


    Monoblock condensing unit is a self-contained refrigeration system where all the components, including the compressor, condenser, and evaporator, are housed within a single unit. These units are commonly used in small refrigeration and air conditioning systems where space is limited, such as in small businesses, restaurants, or households.



    Side Embedded Fixed Frequency Monoblock Unit
    ModelVoltagePowerPackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-YTCN10220V220V/50Hz
    		670*880*800113≤7m³≤12m³
    220V/60Hz
    XMJL-YTCN20220V220V/50Hz820*1000*1000130≤15m³≤25m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN30
    		220V220V/50Hz1050*1000*1000165≤25m³≤40m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN40380V
    		380V/50Hz1120*1070*1060190≤35m³≤55m³


    Side Embedded Frequency Conversion Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-BYTCN10220V/50HZ/60Hz670*880*800113≤7m³≤12m³
    XMJL-BYTCN20220V/50HZ/60Hz820*1000*1000130≤15m³≤25m³
    XMJL-BYTCN30220V/50HZ/60Hz1050*1000*1000165≤25m³≤40m³
    XMJL-BYTCN40220V/50HZ/60Hz1120*1070*1060185≤35m³≤55m³
    Top Mounted Fixed Frequency Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)
    		Product Weight(kg)Freezer Room Volume

    Cold Room Volume

    XMJL--YTDN10220V/50Hz1000*570*81095≤7m³≤12m³
    220V/60Hz
    XMJL--YTDN20220V/50Hz1240*635*810125≤15m³≤25m³
    220V/50Hz
    380/50Hz
    XMJL--YTDN30220V/50Hz
    		1410*670*865150≤25m³≤40m³
    220V/60Hz
    380V/50Hz


    Product Display


    The advantage of a monoblock condensing unit is its compact design and ease of installation. Since all components are integrated into one unit, installation and maintenance are relatively straightforward compared to systems with separate components. Monoblock condensing units are also known for their energy efficiency and can be found in various applications.
