    XMJL 3HP China Monoblock Condensing Unit For Cold Room Supplier

    You need to provide the following information, and Xiamen Jialiang will recommend a suitable solution for you:


    1. Cold storage area and volume

    2.Use venue (indoor or outdoor)

    3. Storage product type

    4. Storage temperature requirements for stored products

    5. Product temperature before storage


    Side Embedded Fixed Frequency Monoblock Unit
    ModelVoltagePowerPackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-YTCN10220V220V/50Hz
    		670*880*800113≤7m³≤12m³
    220V/60Hz
    XMJL-YTCN20220V220V/50Hz820*1000*1000130≤15m³≤25m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN30
    		220V220V/50Hz1050*1000*1000165≤25m³≤40m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN40380V
    		380V/50Hz1120*1070*1060190≤35m³≤55m³


    Side Embedded Frequency Conversion Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-BYTCN10220V/50HZ/60Hz670*880*800113≤7m³≤12m³
    XMJL-BYTCN20220V/50HZ/60Hz820*1000*1000130≤15m³≤25m³
    XMJL-BYTCN30220V/50HZ/60Hz1050*1000*1000165≤25m³≤40m³
    XMJL-BYTCN40220V/50HZ/60Hz1120*1070*1060185≤35m³≤55m³
    Top Mounted Fixed Frequency Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)
    		Product Weight(kg)Freezer Room Volume

    Cold Room Volume

    XMJL--YTDN10220V/50Hz1000*570*81095≤7m³≤12m³
    220V/60Hz
    XMJL--YTDN20220V/50Hz1240*635*810125≤15m³≤25m³
    220V/50Hz
    380/50Hz
    XMJL--YTDN30220V/50Hz
    		1410*670*865150≤25m³≤40m³
    220V/60Hz
    380V/50Hz


    Product Details.
    Customized Services    Installation method: During installation, you only need to open a hole in the library body, insert the unit, and connect the power supply. No debugging is required, greatly reducing installation time and labor costs.


    All our products can be customized and accessories are CE certified. Our products undergo strict quality inspection during processing before delivery. If necessary, we can film every step of the process and send it to the client.


    FAQ

    Q1: How does the XMJL monoblock condensing unit ensure a stable temperature?
    A1: The XMJL monoblock condensing unit achieves a stable temperature through an intelligent control system and highly efficient refrigeration technology.
    Q2: Is remote monitoring capability available for the XMJL monoblock condensing unit?
    A2: Certainly, a large number of XMJL monoblock condensing units come equipped with remote monitoring systems, enabling users to monitor the unit's operation status in real-time.
