Factory Outlet Single Phase Or Three Phase Condensing Unit
Refrigeration condensing Unit With Danfoss compressor.
1. Refrigerant: R404a.
2. Temperature Range: -18°C.
3. Original and handsome shape,light and reasonable structure,convenient installation.
4. Use efficient, low power, low noise and strong-wind axial fan motor.
Single Phase Condensing Unit Special Voltage (60Hz) | ||||||
Model | MLZ015 | MLZ019 | MLZ021 | MLZ026 | MLZ030 | MLZ038 |
Horse Power | 2HP | 2.5HP | 3HP | 3.5HP | 4HP | 5HP |
Compressor | Danfoss | |||||
Refrigeration Capacity | 4100W | 5500W | 5800W | 7200W | 8500W | 10200W |
Btu/h | 14000 | 18800 | 19800 | 24600 | 29000 | 34800 |
Input Power | 2.1W | 2.58W | 2.74W | 3.44W | 3.9W | 4.7W |
COP(W/W) | 1.94 | 2.11 | 2.13 | 2.1 | 2.18 | 2.18 |
EER(Btu/h/W) | 6.62 | 7.2 | 7.27 | 7.17 | 7.44 | 7.44 |
cm3/rev | 33.8 | 43.5 | 46.2 | 57.1 | 68.8 | 81 |
m3/h | 7.1 | 9.1 | 9.7 | 12 | 14.4 | 17 |
Oil Injection Volume | 1.1L | 1.1L | 1.1L | 1.1L | 1.6L | 1.6L |
Net Weight (With Oil) | 31kg | 31kg | 31kg | 31kg | 37kg | 37kg |
Condensing Temperature | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ |
Voltage Range | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) |
Three Phase Condensing Unit Special Voltage (60Hz) | ||||||
Model | MLZ015 | MLZ019 | MLZ021 | MLZ026 | MLZ030 | MLZ030 |
Horse Power | 2HP | 2.5HP | 3HP | 3.5HP | 4HP | 5HP |
Compressor | Danfoss | |||||
Refrigeration Capacity | 4100W | 5500W | 5800W | 7200W | 8500W | 10200W |
Btu/h | 14000 | 18800 | 19800 | 24600 | 29000 | 34800 |
Input Power | 2.1W | 2.58W | 2.74W | 3.44W | 3.9W | 4.7W |
COP(W/W) | 1.94 | 2.11 | 2.13 | 2.1 | 2.18 | 2.18 |
EER(Btu/h/W) | 6.62 | 7.2 | 7.27 | 7.17 | 7.44 | 7.44 |
cm3/rev | 33.8 | 43.5 | 46.2 | 57.1 | 68.8 | 81 |
m3/h | 7.1 | 9.1 | 9.7 | 12 | 14.4 | 17 |
Oil Injection Volume | 1.1L | 1.1L | 1.1L | 1.1L | 1.6L | 1.6L |
Net Weight (With Oil) | 31kg | 31kg | 31kg | 31kg | 37kg | 37kg |
Condensing Temperature | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ |
Voltage Range | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) | 220V(60Hz) |
Customized Services
Our Danfoss cold room refrigeration units product advantages
1. High volumetric efficiency: The scroll compressor has small pressure difference between adjacent spaces, small leakage, no suction and exhaust valves, small resistance, and the volume of the free space no longer expands.
2. Danfoss compressors use a solid cast iron body to provide a larger heat dissipation area and improve the cooling effect of the compressor.
FAQ
Q1: Does a danfoss condensing unit support automation control? |
A1: Yes, modern danfoss condensing units usually support automation control, allowing automatic adjustment of parameters such as temperature and humidity through intelligent systems, thereby enhancing operational efficiency and stability. |
Q2: What is the noise level of a danfoss condensing unit? |
A2: The noise level of a danfoss condensing unit is typically low, but the specific level depends on the unit's model and design. High-quality units are often equipped with noise reduction technology to minimize noise. |
