    4DES-5Y 5HP Home Use AC Condenser Unit

    1. Compact and Aesthetically Pleasing Design:** The entire unit boasts a compact structure and an attractive appearance, enhancing its visual appeal.

    2. Bitzer Compressor for Low Noise and High Reliability:** Utilizing a Bitzer compressor ensures minimal noise, low vibration, and exceptional operational reliability.

    3. Efficient Heat Exchange:** Incorporates copper tubes and aluminum fin heat exchangers, providing a large air surface area for superior heat exchange efficiency.

    4. Longevity:** The unit is designed for high heat exchange efficiency, contributing to a long service life.

    Brand NameXiamen Jialiang
    Compressor4DES-5Y
    Compressor BrandBitzer
    Capacity Steps100%
    Warranty1 Year
    Temperature Range- 11 °C ~ -28 °C
    Refrigeration Unit BrandXiamen Jialiang
    Cooling Capacity（The temperature is 0℃）7.89 KW
    Evaporator Capacity（The temperature is 0℃）7.89 KW
    Power Input（The temperature is 0℃）4.77 KW
    Current (400V)8.58 A
    Horse Power5 HP
    Voltage Range380-420V
    SizeCustomzised
    Compressor TypeSemi-hermitic Reciprocating Compressors
    RefrigerantR22/R404a/R447a/R448a/R449a/R507a
    Refrigeration TypeAir Cooled/Water Cooled/Evaporation Cooled

    Customized Services

    If you're uncertain about which model of condensing unit best suits your needs, please don't hesitate to reach out to us. Once you've shared your requirements, we're more than happy to provide you with our expert recommendations. Our team of skilled engineers, coupled with advanced software, enables us to design a product tailored specifically to your needs. Your satisfaction is our priority, and we're here to assist you in making the right choice.

    FAQ


    Q1: Could you please provide the installation procedure for the 4DES-5Y condenser unit  refrigeration equipment

    A1: We will send layout diagrams and English installation videos, and have a dedicated after-sales group that can provide remote guidance for you.

    Q2: Which market is the primary consumer of the 4DES-5Y condenser unit  products?

    A2: Our products are all over the country
