    • Hot sales commercial XMJL 4HP Commercial Portable Monoblock Condensing Unit

    • Precision Manufacturing with All-in-One Machines

      • 4HPXiamen JialiangR404aAir Cooled
    • Get A Quote
    • Description
    • Features

    XMJL 4HP Commercial Portable Monoblock Condensing Unit

    You need to provide the following information, and Xiamen Jialiang will recommend a suitable solution for you:


    1. Cold storage area and volume


    2.Use venue (indoor or outdoor)


    3. Storage product type


    4. Storage temperature requirements for stored products


    5. Product temperature before storage




    Side Embedded Fixed Frequency Monoblock Unit
    ModelVoltagePowerPackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-YTCN10220V220V/50Hz
    		670*880*800113≤7m³≤12m³
    220V/60Hz
    XMJL-YTCN20220V220V/50Hz820*1000*1000130≤15m³≤25m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN30
    		220V220V/50Hz1050*1000*1000165≤25m³≤40m³
    220V/60Hz
    380V380/50Hz
    XMJL-YTCN40380V
    		380V/50Hz1120*1070*1060190≤35m³≤55m³


    Side Embedded Frequency Conversion Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)Product Weight(kg)Freezer Room VolumeCold Room Volume
    XMJL-BYTCN10220V/50HZ/60Hz670*880*800113≤7m³≤12m³
    XMJL-BYTCN20220V/50HZ/60Hz820*1000*1000130≤15m³≤25m³
    XMJL-BYTCN30220V/50HZ/60Hz1050*1000*1000165≤25m³≤40m³
    XMJL-BYTCN40220V/50HZ/60Hz1120*1070*1060185≤35m³≤55m³
    Top Mounted Fixed Frequency Monoblock Unit
    ModelSupply VoltagePackaging Size (mm)
    		Product Weight(kg)Freezer Room Volume

    Cold Room Volume

    XMJL--YTDN10220V/50Hz1000*570*81095≤7m³≤12m³
    220V/60Hz
    XMJL--YTDN20220V/50Hz1240*635*810125≤15m³≤25m³
    220V/50Hz
    380/50Hz
    XMJL--YTDN30220V/50Hz
    		1410*670*865150≤25m³≤40m³
    220V/60Hz
    380V/50Hz





    Customized Services

    Contact Us
    Q1: How does the XMJL monoblock condensing unit maintain a stable temperature?
    A1: The XMJL monoblock condensing unit maintains a stable temperature through an intelligent control system and efficient refrigeration technology.
    Q2: Does the XMJL monoblock condensing unit have remote monitoring capability?
    A2: Yes, many XMJL monoblock condensing units are equipped with remote monitoring systems, allowing users to monitor the operation status in real-time.
    FAQ
    All our products can be customized and accessories are CE certified. Our products undergo strict quality inspection during processing before delivery. If necessary, we can film every step of the process and send it to the client.

    Product Details.
