- High Performance 7.5HP Condensing Unit
Intelligent remote monitoring condensing unit system
- Get A Quote
7.5HP 380V(50hz) 440v(60Hz) 220V(50hz)
- Description
- Features
High Performance 7.5HP Condensing Unit
| Three Phase Condensing Unit | ||||||
| Model | MLZ042 | MLZ045 | MLZ048 | MLZ058 | MLZ066 | MLZ076 |
| Horse Power | 5.5HP | 6HP | 7HP | 7.5HP | 9HP | 10HP |
| Compressor | Danfoss | |||||
| Refrigeration Capacity | 11800W | 12400W | 13500W | 15700W | 18400W | 20900W |
| Btu/h | 40300 | 42300 | 46100 | 53600 | 62800 | 71300 |
| Input Power | 5.73W | 5.64W | 6.15W | 7.35W | 8.4W | 9.59W |
| COP（W/W） | 2.07 | 2.19 | 2.2 | 2.14 | 2.18 | 2.18 |
| EER（Btu/h/W） | 7.06 | 7.47 | 7.51 | 7.3 | 7.44 | 7.44 |
| cm3/rev | 93.1 | 98.6 | 107.5 | 126 | 148.8 | 162.4 |
| m3/h | 19.6 | 20.7 | 22.6 | 26.4 | 31.3 | 34.1 |
| Oil Injection Volume | 1.6L | 1.6L | 1.6L | 2.7L | 2.7L | 2.7L |
| Net Weight (With Oil) | 37kg | 37kg | 37kg | 44kg | 45kg | 45kg |
| Condensing Temperature | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ |
| Voltage Range | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) | 440v(60Hz) |
| Three Phase Condensing Unit | ||||||
| Model | MZL042 | MZL045 | MZL048 | MZL058 | MZL066 | MZL076 |
| Horse Power | 5.5HP | 6HP | 7HP | 7.5HP | 9HP | 10HP |
| Compressor | Danfoss | |||||
| Refrigeration Capacity | 9500W | 10200W | 11100W | 13000W | 15100W | 17300W |
| Btu/h | 32400 | 34800 | 37900 | 44400 | 51500 | 59000 |
| Input Power | 4.72W | 4.81W | 5.17W | 6.08W | 7.01W | 7.93W |
| COP（W/W） | 2.02 | 2.11 | 2.14 | 2.13 | 2.15 | 2.18 |
| EER（Btu/h/W） | 6.89 | 7.2 | 7.3 | 7.27 | 7.34 | 7.44 |
| cm3/rev | 93.1 | 98.6 | 107.5 | 126 | 148.8 | 162.4 |
| m3/h | 16.2 | 17.2 | 18.7 | 21.9 | 25.9 | 28.3 |
| Oil Injection Volume | 1.6L | 1.6L | 1.6L | 2.7L | 2.7L | 2.7L |
| Net Weight (With Oil) | 37kg | 37kg | 37kg | 44kg | 45kg | 45kg |
| Condensing Temperature | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ | 40℃ |
| Evaporation temperature (-15 ℃) | ||||||
| Refrigeration Capacity (W) | 8.54 | 9.38 | 10.75 | 12.46 | 7.04 | 8.08 |
| Output Power (W) | 4.34 | 4.79 | 5.38 | 6.19 | 14.78 | 17.11 |
| Voltage Range | 380V(50hz) | 380V(50hz) | 380V(50hz) | 380V(50hz) | 380V(50hz) | 380V(50hz) |
Customized Services
FAQ
Q1: How could I choose suitable refrigeration equipment? |
A1: Please provide the size and temperature of the cold storage, our engineer will recommend to you. |
Q2: What is the operating temperature range of a danfoss condensing unit? |
A2: The operating temperature range of a danfoss condensing unit is typically between -18℃ to 10℃ t, depending on the design and specifications of the unit. |
