Condensing Unit
    • Exquisite And Delicate Cold Freezer Room Low Temp Two Stage Condensing Unit

    • Xiamen Jialiang's Expertly Designed Two-Stage 3-Ton Condensing Unit for Low-Temperature Applications

      • 5HP8HP12HP16HP20HP25HP30HPBitzerXiamen Jialiang-35℃
    • Get A Quote
    • Description
    • Features

    Freezer Room Low Temp Two Stage Condensing Unit


    Equipped with CompressorS4T5.2YS4N8.2Y
    Temperature-35℃
    Capacity Level100%
    Refrigeration Capacity (0 ℃)4.46KW6.36KW
    Evaporator Capacity
    		4.46KW
    		6.36KW
    Input Power3.99KW5.70KW
    Current 400V7.21A9.86A
    Voltage Range-35℃
    HP5HP8HP
    Equipped with CompressorS4G12.2YS6J16.2YS6H20.2YS6G25.2YS6F30.2Y
    Temperature-11~-28℃
    Capacity Level100%
    Refrigeration Capacity (0 ℃)10.23KW14.57KW16.83KW19.24KW22.8KW
    Evaporator Capacity10.23KW14.57KW16.83KW19.24KW22.8KW
    Input Power7.57KW12.01KW13.92KW15.98KW19.12KW
    Current 400V13.67A20.3A23.6A27.5A33.2 A
    Voltage Range380-420V
    HP12HP16HP20HP25HP30HP


    Customized Services



    FAQ

    Q1: What is a Bitzer condensing unit?
    A1: A Bitzer condensing unit is a refrigeration equipment designed for refrigeration or freezing storage. It includes key components such as compressors, condensers, and evaporators, used to maintain a stable low temperature inside the cold storage.
    Q2: What is the working principle of a Bitzer condensing unit?
    A2: The working principle of a Bitzer condensing unit is based on the principle of refrigeration cycle to lower the temperature inside the cold storage. It achieves refrigeration through processes like compression, condensation, expansion, and evaporation.
