Condensing Unit
    • Environmental Protection Material Compressor Factory Price Semi Hermetic Condensing Unit for Cold Room

    • Xiamen Jialiang's Affordable Semi-Hermetic Cold Storage Condenser Unit: Quality Meets Affordability

      • 3HP4HP5HP6HP10HP12HP15HP20HP25HPXiamen Jialiang-11℃~-28℃
    • Get A Quote
    • Description
    • Features

    Factory price cold storage semi-closed condensing unit


    Equipped with Compressor4FC-3.24EC-4.24DC-5.24CC-6.24VCS-6.24TCS-8.2
    Condensing Temperature40℃
    Temperature Range-11℃~-28℃
    Refrigeration Capacity (-5 ℃)11.5KW14.4KW17.6KW21.1KW22.7KW27.7KW
    Evaporator Capacity11.5KW14.4KW17.6KW21.1KW22.7KW27.7KW
    Engine Displacement (50Hz) m/h18.0522.7226.8432.4834.7341.33
    Current 400V9.2A10.7A13.5A15.9A14A17A
    Voltage Range380~420YY/3/50

    440~480YY/3/60

    HP3HP4HP5HP6HP6HP4HP
    Equipped with Compressor4PCS-10.24NCS-12.24H-15.24G-20.26H-25.2
    Condensing Temperature40℃
    Temperature Range-11℃~-28℃
    Refrigeration Capacity (-5 ℃)32.2KW37.3KW50.8KW58.3KW74.7KW
    Evaporator Capacity32.2KW37.3KW50.8KW58.3KW74.7KW
    Engine Displacement (50Hz) m/h48.556.2573.673.6110.5
    Current 400V21A24A31A37A45A
    Voltage Range380~420YY/3/50

    440~480YY/3/60

    HP10HP12HP15HP20HP25HP


    Customized Services


    FAQ

    Q1: Does Xiamen Jialiang condensing unit need regular dust removal?
    A1: Yes, condensing units require regular dust removal to ensure the ventilation system remains unobstructed and maintain cooling efficiency.
    Q2: What are the types of refrigerants used in Xiamen Jialiang condensing unit?
    A2: Common types of refrigerants used in condensing units include ammonia, fluorocarbons, propane, etc. Different models of units may use different types of refrigerants.
