    4CC-6.2 6HP New Design Beautiful Condensing Unit

    1. Open-Style Design for Easy Handling: The open-type design simplifies the process of moving, installing, and maintaining the unit, offering convenience and accessibility when needed.

    2. Integrated High and Low Pressure Controllers: Our units are equipped with high and low-pressure controllers, serving as safeguards for the entire bitzer compressor system. These controllers act to protect the equipment in case of breakdowns or overloads, enhancing system reliability.

    3. Comprehensive Component Selection: The condensing unit comprises essential components, including the compressor, condenser, receiver tank, filter drier, solenoid valve, pressure controller, pressure gauge, connection box, and electrical controller box. Each component is carefully chosen to ensure optimal performance and system functionality.

    Brand NameXiamen Jialiang
    Compressor4CC-6.2
    Compressor BrandXiamen Jialiang
    Condensing Temperature40℃
    Warranty1 Year
    Temperature Range- 11 °C ~ - 28 °C
    Refrigeration Unit BrandXiamen Jialiang
    Cooling Capacity（The temperature is -5℃）21.1 KW
    Evaporator Capacity（The temperature is -5℃）21.1 KW
    Voltage Range

    380~420YY/3/50

    440~480YY/3/60

    Engine Displacement (50Hz) m/h32.48m
    Current (400V)15.9A
    Horse Power6 HP
    SizeCustomzised
    Compressor TypeSemi-hermitic Reciprocating Compressors
    RefrigerantR22/R404a/R447a/R448a/R449a/R507a
    Refrigeration TypeAir Cooled/Water Cooled/Evaporation Cooled

    Customized Services

    Features of Our Freezer Condensing Unit:

    - Compact and Elegant Design: Our units feature a streamlined design that not only occupies minimal space but also adds an aesthetic touch to any setting.

    - Ready-to-Install: Delivered fully assembled, our units are primed for immediate installation. This approach not only expedites the setup process but also offers significant savings on assembly and associated costs.

    - Broad Operating Spectrum: Designed for versatility, our units boast a wide operating range, ensuring reliable performance across various conditions and applications.

    FAQ

    Q1: Can we customize the 4CC-6.2 condensing unit with our own logo or branding?

    A1: Yes, we welcome customization and are open to incorporating your logo or branding.

    Q2: Is there an additional cost for customizing the 4CC-6.2 condensing unit with our own brand?

    A2: No, the OEM service is provided at no extra cost.
