    • 6HP Exquisite And Simple Compressor Condensing Units

    • Improve cooling efficiency and reduce operating costs

      • 6HP 380V(50hz) 440v(60Hz) 220V(50hz)
    • Get A Quote
    • Description
    • Features

    6HP Exquisite And Simple Compressor Condensing Units



              Three Phase Condensing Unit
    ModelMLZ042MLZ045MLZ048MLZ058MLZ066MLZ076
    Horse Power5.5HP6HP7HP7.5HP9HP10HP
    CompressorDanfoss
    Refrigeration Capacity11800W12400W13500W15700W18400W20900W
    Btu/h403004230046100536006280071300
    Input Power5.73W5.64W6.15W7.35W8.4W9.59W
    COP（W/W）2.072.192.22.142.182.18
    EER（Btu/h/W）7.067.477.517.37.447.44
    cm3/rev93.198.6107.5126148.8162.4
    m3/h19.620.722.626.431.334.1
    Oil Injection Volume1.6L1.6L1.6L2.7L2.7L2.7L
    Net Weight (With Oil)37kg37kg37kg44kg45kg45kg
    Condensing Temperature40℃
    		40℃40℃40℃40℃40℃
    Voltage Range440v(60Hz)440v(60Hz)440v(60Hz)440v(60Hz)440v(60Hz)440v(60Hz)



    Customized Services




    FAQ

    Q1: The voltage is 110V, can it be used?   ?

    A1: No, refrigeration equipment in the Chinese market can only produce at least 220V.

    Q2: What is the operating temperature range of a danfoss condensing unit?

    A2: The operating temperature range of a danfoss condensing unit is typically between -18℃ to 10℃ t, depending on the design and specifications of the unit.
