    4CC-9.2 9HP High Performance Cold Room Condensing Unit

    Characteristics of the Compressor Condenser Unit


    1. Labor-saving Design**: The plate work structure is well-formed and lightweight, reducing the need for extensive labor during installation.


    2. Time-efficient Installation**: The use of bell-like mouth connectors for the connecting tubes significantly speeds up the installation process, potentially saving up to 50% of installation time. Installation is as straightforward as setting up an air conditioner.


    3. Noise Reduction Technology**: The units incorporate fans designed at a wide angle, along with additional noise-reducing technologies like pit-impressing. This ensures a quieter refrigeration operation.


    4. Anticorrosive Shell**: The unit is constructed with anticorrosive galvanized sheet steel that has undergone rigorous salt spray testing. Additionally, it features an extra spray coating, making it suitable for harsh weather conditions and environments.


    5. Convenient Maintenance**: Equipped with check valves in both the inlet and outlet, installation and maintenance are made easier for the user.

    Brand NameXiamen Jialiang
    Compressor4CC-9.2
    Compressor BrandXiamen Jialiang
    Condensing Temperature40℃
    Warranty1 Year
    Temperature Range-10℃~15℃
    Refrigeration Unit BrandXiamen Jialiang
    Cooling Capacity（The temperature is -5℃）21.0 KW
    Evaporator Capacity（The temperature is -5℃）21.0 KW
    Voltage Range

    380~420YY/3/50

    440~480YY/3/60

    Engine Displacement (50Hz) m/h32.48 m
    Current (400V)20 A
    Horse Power9 HP
    SizeCustomzised
    Compressor TypeSemi-hermitic Reciprocating Compressors
    RefrigerantR22/R404a/R447a/R448a/R449a/R507a
    Refrigeration TypeAir Cooled/Water Cooled/Evaporation Cooled

    Customized Services

    We aspire to be more than just successful businessmen; our true aspiration is to become skilled craftsmen. The pursuit of creating the perfect machine has always captivated us. Currently, our products are making their mark in South America, and it's our unwavering commitment to stable quality, competitive pricing, and prompt service that continues to attract an increasing number of customers.

    In the future, we firmly believe that our refrigeration condensing units will enhance your quality of life, offering you a fresher experience. We're dedicated to realizing this dream together with you, and through our collaboration, we aim to enable more people to savor the benefits of a higher quality of life.

    FAQ

    Q1: Can we customize the 4CC-9.2 condensing units with our own company logo?

    A1: Yes, we are receptive to customizing products according to your requirements.

    Q2: Is there an additional cost for the OEM service on the 4CC-9.2 condensing units, and if so, how much

    A2: No, there are no additional fees for the OEM service.
